Concentric Ultra Light Double Gear (0,8 Module 14T- 50T) Ø5mm
The 0.8 Module (32 Pitch) 14T–50T Concentric Compound Spur Gear is a precision-machined, one-piece hardened steel gear designed for compact, high-performance gear reduction systems. Manufactured from a single steel billet and hardened after machining, it delivers exceptional strength, rigidity and durability under high torque and impact loads.
Unlike welded or press-fit compound gears, its monoblock construction eliminates weak joints, providing superior reliability and consistent power transmission in demanding applications.
Designed with a 14-tooth pinion and a 50-tooth spur gear on the same axis, this compound gear is ideal for creating compact reduction stages. CNC-machined weight-relief pockets and lightening holes reduce rotating mass, improving acceleration and efficiency without compromising strength.
This gear is an excellent choice for sumo robots, combat robots, battle robots, custom gearboxes, robotics competitions and high-performance mechanical drive systems.
Technical Specifications:
Product Type: Concentric Compound Spur Gear
Material: Hardened Steel
Module: 0.8 Module (32 Pitch)
Number of Teeth: 14T / 50T
Overall Thickness: 11.2 mm
Gear Thickness: 5 mm / 4.5 mm
Outside Diameter: 12.7 mm / 41.58 mm
Bore Diameter: 5 mm
Weight: 25.5 g
Applications:
- Mini Sumo Robots
- Mega Sumo Robots
- Combat Robots
- Battle Robots
- Robot Gearboxes
- Gear Reduction Systems
- Mechanical Power Transmission
- Robotics Competitions
- Industrial Automation
- R&D and Prototype Projects
Important Note !
This gear is designed to operate with 0.8 Module (32 Pitch) compatible gears. For optimum performance, use it with matching gears and properly aligned shafts. The lightweight CNC-machined design helps reduce rotating mass, making it particularly suitable for high-performance robotic drive systems.
Delivery Information:Same Day shipping from stock.FeaturesGear Type:Spur GearModule:0.8 ModuleHole Diameter:5 mmMaterial:Steel -
Size (cm):3.200000047683716 x 3.200000047683716 x 3.200000047683716Height (cm):1Weight (Kg):0.03099999949336052
-
