ES08MA II Micro Servo Motor

Product Code: ES08MAII
10.50 USD
Jsumo Robot parts shipment and price information
  • Features
  • Dimensions
  • Comments (0)
  • Payment Options
  • How Will We Ship To You?
  • Servo Motor Features

    Model: Emax Servos ES08MAII Micro Servo
    Control System: PPM
    Working Frequence: 1520μs / 50hz
    (RX) Required Pulse: 3.0 ~ 5 Volt Peak to Peak Square Wave
    Operating Voltage: 4.8 ~ 6 V DC Volts
    Operating Speed (4.8v): 0.12 Sec/60 Degrees
    Operating Speed (6v) 0.10 Sec/60 Degrees
    Stall Torque (4.8v): 21 oz/in (1.5kg/cm)
    Stall Torque (6v): 25.2 oz/in  (1.8kg/cm)
    Motor Type: Brushed DC Motor
    Gear Type: Metal Brass Gears
    Case Material: Plastic
    Programmable: NO
    Connector Wire Length: 24.0cm (9.4 inch)
    Dimensions: 23 x 11.5 x 24mm
    Weight: 12 grams

    What JSumo liked about This servo motor?

    • Micro size, with metal gears it adds extra strength.
    • Good price.
    • Easy to work with not need to program.
    • This servo motor can be used directly with Arduino's servo motor libraries.

    Where can be used?

    • Robot arms, grippers. Animatronics
    • Bug robots.
    • Micro sumo projects (Needs lots of modification sure)
    • Sumo robot flag trigger mechanisms.
  • Size (cm)
    :
    4 x 4 x 4
    Height (cm)
    :
    2
    Weight (Kg)
    :
    0.069
